Description
Model No.: FE-EW-16G
The eye wash unit is designed mainly for wall mounting applications but can be used as a standalone unit on a shelf or a bench.
Specification:
• Material: Made of high-density polyethylene.
• Capacity: Maximum capacity of 60L (16 gallons), with an effective working capacity of 40L, ensuring a continuous 15-minute flush.
• Water Injection Hole: Wide opening for easy water filling, equipped with a dust cover for protection.
• Color: Eco-friendly green, visually appealing, and highly noticeable.
• Water Flow: Optimized nozzle design for a gentle yet effective flow, providing a minimum output of 1.5L per minute.
Features & Benefits:
- Compact and portable gravity-fed eyewash unit, delivering a continuous flow of water for a minimum of 15 minutes.
• Activation is simple—just pull down the eyewash tray to start the water flow.
• Spray nozzles remain protected from dust, debris, and damage when the tray is closed.
• Constructed from UV-stabilized high-density polyethylene (HDPE), with a bright yellow fold-down tray for easy visibility. - Integrated molded handle on top ensures convenient handling & is designed to fit securely on the included wall-mounting bracket.
• Wide-fill opening with threaded cap allows for quick and easy filling, inspection & cleaning.
• Supplied with a wall bracket for easy installation.
• Fully compliant ANSI Z358.1:2020 standards as a self-contained eyewash unit.
Component List:
• Eye Wash Station
- Wall Mounting
• Bracket AssemblyMaintenance:
• Weekly Inspection
• Monthly Water Replacement
• Nozzle and Dust Cover Cleaning
• Flow Rate Testing (Every 2-4 Weeks) - Annual Full InspectionInstallation Procedure:
1. Unpacking and Inspection
2. Selecting the Installation Location
3. Filling the Eyewash Tank
4. Positioning and Mounting (If required)
5. Testing the Unit
6. Final Checks and Readiness
